KLW-093•Product No.: KLW-093
•Unit size: Body: 220*140*332mm (W x D x H), heightening pad:134*134*50mm
•Color: Black
•Power: 28W
•Rated voltage: 100-240V,50-60Hz
•Control mode: Toggle switch
•Suction gear: Gear 3 (high gear 4600rpm, middle gear 4000rpm, low gear 3500rpm)
•Oil separator: Φ140mm, 1.5mm thick
•Activated carbon filter screen: Φ140mm, 5mm thick
•power cord: 1.2 m
•Plug: GS,UK,PSE,US
•Warranty:1 year
•Certification information:GS,CE-LVD,CE-EMC,UKCA-LVD,UKCA-EMC,CB,ETL
1. Place the product on a horizontal plane. If it is not high enough, please install a heightening pad.
2. Keep a distance of 5-10cm between the mobile product and the cooker.
3. Plug the power plug into a suitable grounding socket.
4. It can be used by toggling the switch, and three suction gears can be selected.
5. When not in use, turn off the power switch first, and then unplug the plug from the socket.
